TRACO POWER TEC20915 DC/DC Converter
The TEC 2 series is a compact 2 Watt SIP-8 DC/DC converter designed for reliable industrial power applications. It features fully regulated outputs, high efficiency with over 20% improvement, and an operating temperature range of -40°C to +95°C. The series offers 1/0-isolation voltage of 1600 VDC, short circuit protection, remote On/Off, and meets safety standards UL 62368-1 and UL 60950-1. Ideal for industrial automation, control systems, and embedded electronics, these converters provide dependable power with excellent thermal performance and low noise characteristics.
TRACO POWER TEC20915 DC/DC Converter Specifications:
- Power: 2 Watts
- Input voltage ranges: 4.5-13.2 VDC, 9-18 VDC, 18-36 VDC, 36-75 VDC, 48 VDC nominal
- Output voltage options: 3.3 V, 5 V, 9 V, 12 V, 15 V
- Output current: up to 500 mA
- Efficiency: up to 86%
- Isolation voltage: 1600 VDC (60 s)
- Operating temperature: -40°C to +95°C
- Case material: Non-conducting black plastic
- Potting: Silicone (UL 94V-0 rated)
- Isolation resistance: ≥1 GΩ
- Isolation capacitance: ≤50 pF
- MTBF: 6,621,000 hours
- Switching frequency: 100 kHz min.
- Dimensions: Compact SIP-8 package, pin pitch 2.54 mm (0.1 inch)
Buy the Traco Power TEC20915 – Reliable DC/DC Converter for Industrial Applications
Purchase the Traco Power TEC 2 Series DC/DC converters online today to ensure reliable power delivery in industrial automation, control systems, and electronics. These compact, high-efficiency modules offer wide temperature ranges, robust isolation of 1600 VDC, and safety compliance, making them ideal for demanding applications. Designed for ease of use with remote On/Off and excellent thermal performance, they guarantee long-term durability and consistent performance. Order now for fast shipping and competitive pricing on these industrial-grade power converters.
Get Traco Power TEC 2 Series today—built for precision, efficiency, and long-lasting durability in demanding industrial environments.
