TRACO POWER TPP15105J Medical Power Supply
This high-efficiency, 15-watt medical power supply offers reinforced double insulation and low leakage current suitable for BF applications. Certified for IEC 60601-1 3rd edition with a compact 1.1" x 2.8" form factor, it supports operation up to 5000 meters altitude and temperatures from -40°C to +70°C. The power supply provides adjustable output voltages, excellent regulation, and low ripple noise, ensuring reliable performance in healthcare devices. Its EMC compliance and safety standards make it ideal for medical and industrial applications requiring high safety and stability.
TRACO POWER TPP15105J Medical Power Supply Specifications:
- Input Voltage AC Range: 85 - 264 VAC, DC Range: 120 - 370 VDC
- Input Frequency: 47 — 63 Hz
- Output Voltage Adjustment: ±10%
- Output Power: 13.2W at 3.3V, 5V, 9V, 12V, 15V, 24V, 36V, 48V
- Output Voltage Tolerance: ±1%
- Ripple and Noise: 40-140 mVp-p depending on model
- Capacitive Load: 470 pF to 6000 pF
- Efficiency: up to 89%
- Operating Temperature Range: -40°C to +70°C (up to 85°C with derating)
- Mechanical Dimensions: 1.1" x 2.8" (28 mm x 71.7 mm)
- Isolation Test Voltage: 5,657 VDC input to output
- Leakage Current: <75 μA
- Protection: Short Circuit, Overvoltage, Overcurrent
- Altitude: Up to 5000 meters
- Compliance: IEC 60601-1, IEC 62368-1, UL 62368-1, EN 60601-1
- Certifications: 2x MOPP, Reinforced insulation
Buy the TracoPower TPP 15-J – Reliable Medical Power Supply for Industrial Applications
Purchase the TracoPower TPP 15-J medical power supply online today to ensure reliable, efficient, and safe operation of your healthcare equipment. With a compact design measuring only 1.1" x 2.8", this certified device offers high efficiency up to 89%, reinforced double insulation, and low leakage current under IEC 60601-1 standards. Its adjustable output, excellent regulation, and low ripple noise make it ideal for critical medical applications. Buy now for guaranteed safety, durability, and compliance with international standards, ensuring seamless integration into your medical devices and industrial systems.
Get TracoPower TPP 15-J today—built for medical precision and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER TPP15105J?
You can click on the BUY or RFQ button to purchase TPP15105J from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP15105J?
You can download the TPP15105J datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP15105J?
TRACO POWER
