TRACO POWER TPP30124D Medical Power Supply
The TPP30124D is a compact, high-efficiency power supply designed for medical devices, offering 24 VDC output at 1,260 mA with up to 92% efficiency. It features reinforced double I/O isolation, low leakage current below 75 μA, and compliance with IEC 60601-1 standards for patient safety. Its universal input range spans 85-264 VAC, supporting operation up to 5000 meters altitude and a wide temperature range from -40°C to +85°C. The power supply includes protections for overvoltage, short circuits, and has EMC compliance, making it ideal for demanding healthcare environments with minimal noise and high reliability.
TRACO POWER TPP30124D Medical Power Supply Specifications:
- Output Voltage: 24 VDC (21.6 - 26.4 VDC)
- Output Current: 1260 mA
- Efficiency: Up to 92%
- Input Voltage Range: 85 - 264 VAC, 120 - 370 VDC
- Power Consumption at no Load: 60 mW max
- Operating Temperature: -40°C to +85°C (derating above 85°C)
- Isolation Test Voltage: 5,000 VDC (input to output)
- Leakage Current: below 75 μA
- Protection Class: II reinforced insulation
- Altitude: Up to 5000 meters
- Dimensions: 50 mm x 73.3 mm x 25.6 mm
- Cooling: Natural convection
- Switching Frequency: 30-60 kHz
- Certifications: IEC 60601-1, IEC 62368-1, UL 60601-1
- Vibration & Shock Resistance: IEC 60068-2-6 & IEC 60068-2-27
- Weight: 106 g
Buy the Buy Traco Power TPP 30-D Series Power Supply Part Number TPP30124D Online
Purchase the Traco Power TPP 30-D Series TPP30124D online today to benefit from a high-quality, medical-grade power supply with reinforced insulation, low leakage current, and outstanding efficiency. Designed for healthcare devices requiring reliable voltage regulation, this unit features an extensive input range of 85-264 VAC, minimal power consumption at no load, and compliance with IEC 60601-1 medical safety standards. Its durable design supports operations at up to 5000 meters altitude and temperatures from -40°C to +85°C, making it the ideal choice for demanding medical environments demanding safety, efficiency, and lasting performance.
Order your Traco Power TPP 30-D Series TPP30124D today and ensure your medical devices operate safely and efficiently with reliable power quality.
Frequently Asked Questions
Where can I buy TRACO POWER TPP30124D?
You can click on the BUY or RFQ button to purchase TPP30124D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP30124D?
You can download the TPP30124D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP30124D?
TRACO POWER
