TRACO POWER TXM100115 Industrial Power Supply
The TXM100115 is a compact, high-efficiency enclosed power supply designed for industrial applications. It features an adjustable 15 VDC output, a maximum current of 10 A, and a power rating of 150 W. The device operates over a wide input voltage range of 100-240 VAC and can withstand surge voltages of up to 300 VAC. Its robust metal case ensures durability, and it offers low no-load power consumption, high operating temperatures up to 70°C, and comprehensive EMC compliance, making it ideal for automation, control systems, and industrial equipment.
TRACO POWER TXM100115 Industrial Power Supply Specifications:
- Output Voltage: 15 VDC (adjustable 14.2-16.5 VDC)
- Output Current Max: 10 A
- Power Rating: 150 W
- Input Voltage Range: 100-240 VAC, 90-264 VAC, 127-370 VDC
- Input Frequency: 47-63 Hz
- Efficiency: 86%
- Ripple and Noise: < 1.0 % of Vout nominal
- Overload Protection: Hiccup mode, automatic recovery
- Over Voltage Protection: 105%-150% of Vout nominal
- Operating Temperature: -20°C to +60°C
- Storage Temperature: -30°C to +85°C
- Isolation Voltage (Input/Output): 3000 VAC
- MTBF: >200,000 hours
- Certifications: UL, cUL, IEC 60950-1, RoHS compliant
- Dimensions: Approximate weight 455 g, case features include pin functions for ACL, ACN, GND, Vout, +Vout
Buy the TRACO 150-115 U+2013 Reliable Power Supply for Industrial Applications
Secure your industrial automation and control systems today by purchasing the TRACO 150-115 power supply online. Designed for durability and efficiency, it provides a stable 15 VDC output with a 10 A capacity, ensuring consistent operation for demanding industrial environments. Its wide input voltage range, low noise, and high efficiency make it suitable for various applications. Enjoy a straightforward installation with its robust metal case, comprehensive safety standards, and 3-year warranty—making it the ideal choice for reliable power management in your operational setup.
Buy TRACO 150-115 now and experience unmatched reliability and performance in industrial power supply solutions.
