TRACO POWER TPC030105 Industrial Power Supply
The TPC power supplies are compact, efficient industrial-grade units designed for reliable operation in industrial, office, and residential environments. They feature adjustable output voltages, low ripple and noise, overload and short-circuit protection, and comply with European ErP directives. With a universal input range of 85-264 VAC or 90-375 VDC, these lightweight DIN-rail power supplies are suitable for various voltage outputs (5 V, 12 V, 24 V, 48 V). They include features such as Power Good signals, high MTBF, and optional redundancy modules for increased reliability, making them ideal for automation, control systems, and reliable power distribution.
TRACO POWER TPC030105 Industrial Power Supply Specifications:
- Input Voltage Range: 85-264 VAC, 47-63 Hz; 90-375 VDC
- Output Voltage: 5 VDC / 5.0-6.0 VDC, 12 VDC / 12-15 VDC, 24 VDC / 24-28.8 VDC, 48 VDC / 48-56 VDC
- Output Power: 30W to 120W depending on model
- Output Current: Up to 40A for 5 V models, 25A for 48 V models
- Efficiency: up to 87% (varies by model)
- Operating Temperature: -25°C to +70°C, derating above 50°C
- Protection: Overload, short-circuit, overvoltage protection
- Ripple & Noise: Max 100 mVpk-pk
- Mounting: DIN-rail or wall bracket included
- Certifications: UL, CB, EN 60950-1, ROHS compliant
- Enclosure Material: Makrolon UL 94V-0
- Dimensions: Ranging from 26.5mm x 90mm x 96.5mm for smallest to larger sizes for higher power models
Buy the Traco Power Series Power Supply: TPC030105
Purchase the Traco Power Series Power Supply TPC030105 online today to guarantee dependable, efficient power delivery for industrial automation, control panels, and residential systems. These compact units feature adjustable output voltages, low ripple, and comprehensive protections, ensuring optimal performance across various environments. Designed with high efficiency and lightweight construction, they are perfect for DIN-rail mounting or wall installation. Equip your industrial or residential projects with a proven power solution accessible online for quick, secure delivery, and reliable operation.
Order your Traco Power Series Power Supply TPC030105 today and ensure your projects benefit from reliable, efficient power with versatility for industrial needs.
Frequently Asked Questions
Where can I buy TRACO POWER TPC030105?
You can click on the BUY or RFQ button to purchase TPC030105 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPC030105?
You can download the TPC030105 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPC030105?
TRACO POWER
