TT Electronics - Optek Technology OP207CL Infrared LED
The OP207CL is a high-power IR LED with a 7mm emission spot diameter, designed for encoder applications like linear and rotary encoders, optical sensors, and light barriers. It features narrow, collimated emission for high occlusion efficiency, low forward voltage, and fast rise and fall times. Suitable for long-distance sensing, the LED operates within -40°C to +105°C, offering high radiant power, reliable performance, and precise light output. Its durable construction ensures consistent operation in diverse industrial and automation environments.
TT Electronics - Optek Technology OP207CL Infrared LED Specifications:
- Storage Temperature Range: -40°C to +105°C
- Operating Temperature Range: -40°C to +105°C
- Reverse Voltage: 10V
- Continuous Forward Current: 100 mA
- Power Dissipation: 190 mW
- Peak Package Body Temperature: 200°C
- Wavelength at Peak Emission: 840-870 nm
- Total Output Radiant Power: 100 mW at 50 mA
- Spot Light Diameter: 7 mm at 1.5 mm distance
- Forward Voltage: 1.9 V at 50 mA
- Rise Time, Fall Time: 22 ns
- Emission Spot Diameter vs. Distance: varies with lens distance
- Beam Half-Intensity Angle: 2.25 Degrees
Buy the TT Electronics Series IR LED: OP207CL
Enhance your optical sensing and encoder applications with the OP207CL infrared LED. Designed for precision and durability, it offers collimated emission, stable performance over temperature ranges from -40°C to +105°C, and high radiant power. Its compact 7mm spot diameter ensures excellent coupling efficiency in long-distance sensing, automation, and detection systems. Perfect for industrial environments, this LED provides fast response times, reliable operation, and efficient light output, making it ideal for high-precision optical applications in automation and control systems.
Get TT Electronics OP207CL today—built for high power IR sensing and long-lasting durability.
Frequently Asked Questions
Where can I buy TT Electronics - Optek Technology OP207CL?
You can click on the BUY or RFQ button to purchase OP207CL from an authorized TT Electronics - Optek Technology distributor.
How do I troubleshoot issues or seek technical support for part OP207CL?
You can download the OP207CL datasheet or visit the TT Electronics - Optek Technology website for support.
Who is the manufacturer of OP207CL?
TT Electronics - Optek Technology
