Telemecanique Sensors XS108B3NAM12. Datasheet & Stock

The XS108B3NAM12 from Schneider Electric / Telemecanique is a general purpose OsiSense XS inductive proximity sensor XS1 for non contact sensing of metal objects. It features best in class quality and immunity to harsh industrial environments. An inductive proximity sensor is comprises an oscillator whose windings constitute sensing face. An alternating magnetic field is generated in front of these windings. When a metal object is placed within magnetic field generated by sensor, the resulting currents induced form additional load and oscillations cease. This causes output driver to operate and depending on sensor type (NO or NC output signal). This sensor enables detection without physical contact of metals. Its range of applications includes monitoring position of machine parts (cams, end stops) and counting presence of metal objects. It also used in assembly machines, machine tools, machining, packaging, materials handling, conveying, food and beverage industry.




45mm size, fixed body, flush mountable detector, metal material, 4 pin M12 male connector

Discrete output signal, 3-wire wiring technique, 1 NO discrete output function, small size

2.5mm nominal sensing distance, DC output circuit type, cylindrical M8 design, M8 x 1 thread type

0 to 2mm operating zone, 1 to 15% of Sr differential travel

Rated supply voltage from 12VDC to 24VDC with reverse polarity protection, weight is 0.060Kg

NPN discrete output type, switching capacity is

IP65 conforming to IEC 60529, IP67 conforming to IEC 60529 degree of protection

Frontal detection face, PPS front material, nickel plated brass enclosure material



CE marked, UL and CSA certified, -25°C to 70°C ambient air temperature for operation





Applications


Automation & Process Control,

Industrial,

Robotics,

Sensing & Instrumentation
