Telemecanique Sensors XUB0APSNM12 Photoelectric Sensor
The XUB0APSNM12 is a versatile multimode photoelectric sensor featuring a PNP output with one normally-open or normally-closed programmable discrete contact. This M18 cylindrical sensor operates with a DC output circuit, capable of sensing metal objects at distances up to 20 meters. It offers reliable performance even in harsh industrial environments, thanks to its high-quality build and immunity to interference. The sensor supports various sensing methods including red polarized reflex, infrared through beam, and infrared diffuse with background suppression. It is equipped with a yellow LED indicating output status, a red LED for stability alerts, and a green LED displaying power supply status. The sensor incorporates a 3-wire wiring method, a 4-pin M12 male connector, and a solid output type. Encased in PBT housing, it features IP69K, IP67, and IP65 protection ratings, suitable for demanding industrial applications such as sensing and instrumentation.
Telemecanique Sensors XUB0APSNM12 Photoelectric Sensor Specifications:
- Detection Range: Up to 20 meters for thru-beam (infrared), 0.12 meters diffuse with background suppression, 0.4 meters diffuse, 30 meters thru-beam, 4.5 meters polarized reflex.
- Sensor Diameter: 18 mm
- Material: PBT enclosure, PMMA lens
- Supply Voltage: 12-24 V DC, reverse polarity protection, 10-36 V DC limits
- Output Type: Solid state PNP, programmable normally-open or normally-closed
- Output Voltage Drop: Less than 1.5 V in closed state
- Current Consumption: 35 mA no-load
- Switching Frequency: Up to 250 Hz
- Certification: UL, CSA, CE
- Protection Class: IP65, IP67, IP69K with double insulation
- Vibration Resistance: 7 gn, IEC 60068-2-6
- Shock Resistance: 30 gn, IEC 60068-2-27
- Operating Temperature: -13 to 131 °F (-25 to 55 °C)
- Storage Temperature: -40 to 158 °F (-40 to 70 °C)
- Dimensions: Diameter 0.71 in (18 mm), Length 3.07 in (78 mm), Weight 0.10 lb (0.045 kg)
Buy the Buy Schneider Electric Photoelectric Sensor Part Number XUB0APSNM12 Online
Secure your Schneider photoelectric sensor XUB0APSNM12 online today and experience seamless integration into your industrial systems. With versatile sensing capabilities including infrared diffuse, through beam, and polarized reflex, this high-performance sensor ensures precise detection up to 20 meters. Its durable PBT housing and IP69K/IP67/IP65 ratings guarantee suitability for harsh environments. Equipped with an intuitive self-teaching setup, red, yellow, and green LEDs for status indication, and a solid-state PNP output, it offers dependable service for automation, manufacturing, and instrumentation projects. Purchase now for efficient and reliable sensing solutions.
Order your Schneider SeriesXUB photoelectric sensor part number XUB0APSNM12 today and enhance your industrial sensing with reliable, multi-mode detection.
