Vishay ILBB0603ER300V Ferrite Bead
The ILBB-0603 ferrite bead from Vishay Dale is a surface-mount component designed for high reliability electromagnetic interference filtering in compact electronic circuits. With a size of 0603, it features a nickel barrier plating that virtually eliminates silver migration, ensuring stability and longevity. Operating within -55°C to +125°C, it exhibits low DCR, high current capacity, and excellent solderability, making it ideal for portable, mobile, and industrial electronic applications requiring efficient noise suppression, thermal stability, and RoHS compliance.
Vishay ILBB0603ER300V Ferrite Bead Specifications:
- Size: 0603 (1.5 x 0.8 mm)
- Operating Temperature: -55°C to +125°C
- DCR at 100 MHz: 0.045 + 0.004 ohms
- DC Current: up to 500 mA (varies with impedance value)
- Impedance values: from 25% to 70% at 100 MHz depending on model
- Material: Magnetically shielded ferrite
- Solderability: 90% coverage after 5 seconds dip at 235°C
- Resistance to solder heat: 10 seconds at 260°C
- Thermal Shock: 100 cycles, -40°C to +125°C
- RoHS Compliant, Nickel barrier plating virtually eliminating silver migration
- Packaging: Tape and Reel options available, compatible with EIA-481-1
Buy the Vishay ILBB-0603 Reliable Ferrite Bead for Industrial Applications
Secure your electronic projects with the Vishay ILBB-0603 ferrite bead, renowned for its compact size, high reliability, and excellent EMI filtering capabilities. This surface-mount component guarantees stable performance within a wide temperature range, features low DCR, and is RoHS compliant. Its rugged construction ensures resistance to thermal shock and soldering heat, making it ideal for dense circuit layouts and industrial applications. Purchase online today for dependable noise suppression, superior quality, and fast delivery to meet your manufacturing needs.
Order your Vishay Series ILBB-0603 ferrite bead today and enhance your electronic circuits with reliable EMI filtering and thermal stability.
Frequently Asked Questions
Where can I buy Vishay ILBB0603ER300V?
You can click on the BUY or RFQ button to purchase ILBB0603ER300V from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part ILBB0603ER300V?
You can download the ILBB0603ER300V datasheet or visit the Vishay website for support.
Who is the manufacturer of ILBB0603ER300V?
Vishay
