A Premier B2B Part Search
Vishay MBB02070C3321FRP00 Thin Film Resistor
Professional thin film leaded resistors designed for high stability and reliability in industrial, automotive, telecommunication, and medical applications. These resistors feature homogeneous metal alloy film deposited on high-grade ceramic, with laser-trimmed precision to achieve specific resistance values. They are RoHS compliant, halogen-free, and available in various TCRs and tolerances, including CECC-approved versions. Suitable for automatic processing, these resistors withstand harsh environmental conditions, deliver excellent thermal stability, and are finished with durable coated termination wires for soldering compatibility. Their wide resistance range and strict quality standards make them ideal for demanding electronic circuits requiring high performance and long-term stability.
Vishay MBB02070C3321FRP00 Thin Film Resistor Specifications:
- Resistance range: 0.22 Q to 22 MQ
- Resistance tolerance: ±5 %, ±1 %, ±0.5 %
- Temperature coefficient: +50 ppm/K, +25 ppm/K
- Rated dissipation: 0.4W (0204), 0.6W (0207), 1.0W (0414)
- Operating voltage: 200 V (0204), 350 V (0207), 500 V (0414)
- Operating temperature range: -55°C to 155°C
- Peak permissible film temperature: 155°C
- Insulation voltage: 300 V (0204), 500 V (0207), 800V (0414)
- Resistance stability after 1000h at high temperature: <0.5%
- Resistance drift over long-term exposure: <15% over 225,000 hours
- Physical dimensions: Dax 1.6-4.2 mm, La 28-31 mm, weight 125-700 mg depending on type
- Features CECC and IECQ-CECC approval, RoHS compliant, halogen-free, laser-trimmed for precision, suitable for automatic insertion
Buy the Vishay 0207 U+2013 Reliable Thin Film Resistors for Industrial Applications
Secure your Vishay thin film resistor online today—engineered for ultimate reliability and stability for industrial, automotive, telecommunication, and medical electronics. These resistors feature high precision laser trimming, RoHS compliance, and CECC approval. Designed to withstand harsh environments, they provide excellent thermal stability, low resistance drift, and long-term performance. Whether you need CECC-certified models or general purpose variants, purchase easily online and ensure your project benefits from proven high-quality resistors that deliver superior electrical and mechanical stability for critical applications.
Get Vishay 0207 today—built for precision, stability, and long-lasting durability in demanding electronic environments.
Frequently Asked Questions
Where can I buy Vishay MBB02070C3321FRP00?
You can click on the BUY or RFQ button to purchase MBB02070C3321FRP00 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MBB02070C3321FRP00?
You can download the MBB02070C3321FRP00 datasheet or visit the Vishay website for support.
Who is the manufacturer of MBB02070C3321FRP00?
Vishay
