Vishay RTO020F100R0JTE3 High Power Resistor
The RTO 20 is a 20 W power resistor featuring thick film technology in a compact TO-220 package, ideal for industrial applications requiring high power dissipation and reliable performance. Its rugged insulated case offers mechanical protection, and it operates over a temperature range of -55°C to +155°C. With low inductance, a wide resistance range from 0.01 Ω to 550 kΩ, and RoHS compliance, it is suitable for various high-power, high-temperature, and precision electronic circuits. Available in radial leaded and surface-mount versions for versatile mounting options.
Vishay RTO020F100R0JTE3 High Power Resistor Specifications:
- Power Rating: 20 W at +25°C with heatsink mounted
- Resistance Range: 0.010 Ω to 550 kΩ (E24 series)
- Tolerance: +1% to +10%
- Temperature Range: -55°C to +155°C
- Thermal Resistance: 6.5°C/W (Rθf), 2 W free air at +25°C
- Temperature Coefficient: ±150 ppm/°C (standard), ranged to +900 ppm/°C
- Maximum Overload Voltage: 375 V
- Dielectric Strength: 2000 V (AC, 1 min)
- Insulation Resistance: 2×10^9 Ω
- Inductance: <0.1 μH
- Environmental Standards: Climatic category 55/155/56, sealed container, RoHS compliant
- Package: TO-220 (radial leads and surface mount options)
- Mechanical Protection: Insulated case, tin-plated copper connections
- Soldering Temperature (surface mount): max 220°C
Buy the VISHAY RTO 20 – Reliable High-Power Resistor for Industrial Applications
Order Vishay RTO 20 power resistor online to ensure high performance in your industrial and high-temperature electronic applications. These rugged resistors are designed with thick film technology and come in a compact TO-220 package, offering wide resistance options from 0.01 Ω to 550 kΩ. Suitable for both PCB and surface mounting, they provide reliable operation over a temperature range of -55°C to +155°C. Ideal for high-power circuits needing efficient heat dissipation, RoHS compliance, and durable mechanical protection, making your projects more efficient and dependable.
Get Vishay RTO 20 today—built for high power dissipation, durability, and versatile mounting options for demanding industrial environments.
Frequently Asked Questions
Where can I buy Vishay RTO020F100R0JTE3?
You can click on the BUY or RFQ button to purchase RTO020F100R0JTE3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part RTO020F100R0JTE3?
You can download the RTO020F100R0JTE3 datasheet or visit the Vishay website for support.
Who is the manufacturer of RTO020F100R0JTE3?
Vishay
