WURTH ELEKTRONIK 156125M173000 Full-color LED Module
The WL-SFRW SMD Full-color Reverse LED includes red, green, and blue emission chips with a rectangular lens type. It features high luminous intensity, low power dissipation, and a wide operating temperature range from -40°C to +85°C. Suitable for display applications, the LED is moisture-sensitive level 3 and complies with safety standards, offering reliable optical performance, peak wavelengths around 632 nm for red, 520 nm for green, and 468 nm for blue. Designed for surface mount technology with waterclear encapsulation, ideal for color display modules and indicator lighting.
WURTH ELEKTRONIK 156125M173000 Full-color LED Module Specifications:
- Emitting Colors: Red, Green, Blue
- Lens Type: Rectangular
- Peak Wavelength (Red): 632 nm
- Peak Wavelength (Green): 520 nm
- Peak Wavelength (Blue): 468 nm
- Luminous Intensity (Red): 28-80 med
- Luminous Intensity (Green): 112-280 med
- Luminous Intensity (Blue): 28-70 med
- Forward Voltage (Red): 2.2 - 2.4 V
- Forward Voltage (Green): 3.3 - 3.9 V
- Forward Voltage (Blue): 3.3 - 3.9 V
- Spectral Bandwidth (Red): 20 nm
- Spectral Bandwidth (Green): 30 nm
- Spectral Bandwidth (Blue): 20 nm
- Peak Forward Current: 40 mA (duty/10 @ 1 kHz)
- Continuous Forward Current: 20 mA
- Reverse Voltage: 5 V
- ESD Threshold: 1000 V
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Moisture Sensitive Level: MSL 3
- Viewing Angle: 120°
- Material: Waterclear encapsulation
Buy the Wirth Elektronik WL-SFRW – Reliable Full-Color LED for Industrial Applications
Order the Wirth Elektronik WL-SFRW full-color SMD LED online today and benefit from high luminous efficiency, wide viewing angles, and reliable optical performance. Whether for display screens, indicator lights, or innovative lighting solutions, this waterclear full-color LED offers outstanding color vibrancy, durability in harsh environments, and easy surface-mount integration. Secure fast delivery and superior quality plasma-compatible components. Enhance your project with this versatile, safety-compliant LED module, designed for easy installation and long-term operation in demanding industrial applications.
Buy Wirth Elektronik WL-SFRW now and experience reliable full-color display performance suitable for industrial and signage applications.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 156125M173000?
You can click on the BUY or RFQ button to purchase 156125M173000 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 156125M173000?
You can download the 156125M173000 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 156125M173000?
WURTH ELEKTRONIK
