WURTH ELEKTRONIK 62102821021 SMT Dual Pin Header
This SMT straight dual pin header features 1.27mm pitch, gold-plated contacts, and complies with RoHS standards. Designed for general electronic applications, it supports a rated current of 1A and withstands voltages up to 500VAC. The component offers high reliability with a contact resistance of maximum 20 milliohms, an insulation resistance exceeding 1000 MΩ, and features a black insulator. Suitable for compact circuit assemblies, it ensures secure connections with a co-planarity of 120μm and is ideal for use in various electronic devices requiring robust and durable connectors.
WURTH ELEKTRONIK 62102821021 SMT Dual Pin Header Specifications:
- Pitch: 1.27 mm
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Number of Pins: 28
- Pin to Pin (Middle): 16.51 mm
- Lengths and sizes: from 2.54 mm to 27.94 mm
- Operating Temperature: ~40 °C up to +105 °C
- Insulator Color: Black
- Insulator Material: PAST
- Flammability Rating: UL94 V-0
- Rated Current: 1 A
- Working Voltage: 500 VAC
- Withstanding Voltage: 1 min 500 VAC
- Contact Resistance: ≤20 mΩ
- Insulation Resistance: ≥1000 MΩ
- Co-planarity: 120 μm
- Packaging Quantity: 32 units
- Soldering Profile: complies with IPC/JEDEC J-STD-020E, preheat min 150°C, max 200°C, peak temperature 260°C
- Max reflow temperature: 260°C for package thickness <1.6 mm
- Storage: in original sealed packaging, use within 12 months for optimal solderability
Buy the Wurth Elektronik Series SMT Dual Pin Header: 62102821021
Enhance your electronic assembly with the Wurth Elektronik SMT Dual Pin Header, designed for durability and precision. With a 1.27mm pitch and gold-plated contacts, it ensures optimal conductivity and reliable connections, ideal for high-density circuit boards. RoHS compliant and rated for 1A current, this component withstands up to 500VAC, making it suitable for a variety of professional applications. Easy to solder with a verified reflow profile, order now online to upgrade your electronic projects with trusted quality and performance.
Order your Wurth Elektronik Series SMT Dual Pin Header 62102821021 today and secure reliable, precise connections for your electronic projects.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 62102821021?
You can click on the BUY or RFQ button to purchase 62102821021 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 62102821021?
You can download the 62102821021 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 62102821021?
WURTH ELEKTRONIK
