WURTH ELEKTRONIK 74404086471 SMD Power Inductor
The Würth Elektronik WE-LQS 74404086471 is a surface-mount power inductor designed for a wide range of electronic applications. This inductor offers a 470µH inductance with a tight tolerance of ±20%, a low DC resistance of 1200 mΩ, and a self-resonant frequency of 1.8 MHz. It is ideal for use in DC-DC converters, power supplies, and filtering circuits. The component is designed for general electronic equipment and is not intended for use in safety-critical applications without proper evaluation and agreement. Operating within a temperature range of -40°C to +125°C, this inductor ensures reliable performance in various environments. It is packaged in tape and reel format, adhering to IEC 60286-3:2013 standards, with a pull-off force between 0.1 N and 1.3 N.
WURTH ELEKTRONIK 74404086471 SMD Power Inductor Specifications:
- Inductance: 470 µH
- Tolerance: ±20%
- Rated Current: 0.65 A
- Saturation Current: 1.08 A
- DC Resistance: 1200 mΩ
- Self Resonant Frequency: 1.8 MHz
- Ambient Temperature: -40 °C up to +85 °C
- Operating Temperature: -40 °C up to +125 °C
- Storage Temperature: -20°C up to +60°C
- Packaging: Tape and Reel
- Tape Width: 16 mm
- Pull-off Force: 0.1 N - 1.3 N
- Preheat Temperature Min: 150 °C
- Preheat Temperature Max: 200 °C
- Preheat Time: 60 - 120 seconds
- Ramp-up Rate: 3 °C/second max.
- Liquidous Temperature: 217 °C
Buy the 74404086471 WURTH ELEKTRONIK SMD Power Inductor | myMectronic
Purchase the Würth Elektronik 74404086471 WE-LQS SMD Power Inductor securely and efficiently through our online store.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 74404086471?
You can click on the BUY or RFQ button to purchase 74404086471 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 74404086471?
You can download the 74404086471 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 74404086471?
WURTH ELEKTRONIK
