WURTH ELEKTRONIK 749023010A LAN Transformer
The LAN-Transceiver WE-LAN is a high-performance transformer designed for Ethernet applications, specifically supporting 1000BaseT networks. Manufactured by WURTH ELEKTRONIK, it ensures reliable data transmission with low insertion loss and excellent electrical characteristics such as high common-mode rejection and impedance matching. Its compact ferrite core construction and RoHS compliance make it suitable for power over Ethernet and industrial networking setups. The component features a durable case tested for UL94-Vo compliance and withstands operating temperatures from 0°C to +70°C, making it ideal for robust industrial environments.
WURTH ELEKTRONIK 749023010A LAN Transformer Specifications:
- Dimensions: 17.50 ± 0.25 mm (A), 6.00 mm (T), 15.24 ± 0.25 mm (Bc), 14.20 ± 0.25 mm (D), 1.20 ± 0.05 mm (E), 0.30 ± 0.10 mm (G), 12.65 ± 0.25 mm (a), 2.3 ± 0.25 mm (b), 2.00 mm max. (c)
- Electrical Properties: Inductance 350 HH min. at 100kHz/100mV @ 8mA, Transmission ratio 1d Tx 3%, Insertion loss -1.0 dB at 100 MHz, -2.0 dB at 125 MHz, Return loss 42 dB min. at 0 MHz, Crosstalk -37 dB min. at 60 MHz
- Material & Construction: Ferrite core, Cu-Ni-Sn contact plating, UL94-Vo rated case, RoHS compliant, suitable for Power over Ethernet (350 mA)
- Testing & Compliance: Tested with HP4395A, withstands 1500 Vrms Hipot testing, operational from 0°C to +70°C
Buy the WURTH ELEKTRONIK 749023010A – Reliable Ethernet Transformer for Industrial Applications
Secure your Ethernet connections with our LAN Transformer designed for industrial settings. This compact, RoHS-compliant component offers high electrical performance including low insertion loss and excellent crosstalk suppression. Suitable for 1000BaseT applications and Power over Ethernet, its robust construction and UL94-Vo rated case ensure durability and safety. Easy to integrate into your network infrastructure, this transformer guarantees reliable data transfer and long-term stability in demanding environments. Order online today and upgrade your industrial communication systems effortlessly.
Order your WURTH ELEKTRONIK 749023010A Ethernet LAN transformer today and enhance your industrial network reliability with proven quality and performance.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 749023010A?
You can click on the BUY or RFQ button to purchase 749023010A from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 749023010A?
You can download the 749023010A datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 749023010A?
WURTH ELEKTRONIK
