WURTH ELEKTRONIK 860040275009 Aluminum Capacitor
This aluminum electrolytic capacitor is designed for electronic applications, offering high reliability and stable performance at operating temperatures from -40°C to +105°C. With a capacitance of 1000µF, rated voltage of 10V DC, and a maximum ripple current of 1110mA at 105°C, it features a vent for pressure relief and an aluminum sleeve for durability. Suitable for use in electronic circuits requiring high safety and reliability, it complies with RoHS and REACH standards. Proper storage, soldering, and handling are essential for optimal performance and safety.
WURTH ELEKTRONIK 860040275009 Aluminum Capacitor Specifications:
- Capacitance: 1000µF
- Rated voltage: 10V DC
- Capacitance tolerance: +20%
- Leakage current after 2 min: 100µA max
- Dissipation factor: 19% typ at 120Hz
- Ripple current: 1110mA max at 105°C
- Impedance: 0.064Ω max at 100kHz, 20°C
- Operating temperature: -40°C to +105°C
- Load life: 6000 hours at +105°C/10V
- Storage: 5°C to 35°C, <75% RH
- Soldering: Wave and hand soldering compatible with precautions
- Physical size: 10.0x16.0mm
- Material: Aluminum with PVC sleeve, RoHS & REACH compliant
- Design includes pressure vent for safety
- Certification: RoHS, REACH
Buy the Buy Wurth Elektronik Aluminum Electrolytic Capacitor Part Number 860040275009 Online
Enhance your electronic projects with the high-quality aluminum electrolytic capacitor from Wurth Elektronik. With 1000µF capacitance, 10V rating, and operating temperature range from -40°C to +105°C, it ensures stable, reliable performance for demanding electronic applications. Featuring a pressure vent for safety and compliance with RoHS and REACH standards, this capacitor is ideal for circuits requiring durability and safety. Purchase online today to benefit from fast delivery and expert support, ensuring your project’s success.
Buy Wurth Elektronik 860040275009 now and experience unmatched reliability and high-performance in your electronic circuits with this quality electrolytic capacitor.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 860040275009?
You can click on the BUY or RFQ button to purchase 860040275009 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 860040275009?
You can download the 860040275009 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 860040275009?
WURTH ELEKTRONIK
