WURTH ELEKTRONIK 860160272003 Aluminum Electrolytic Capacitor
The WURTH ELEKTRONIK WCAP-ATLL aluminum electrolytic capacitor is a robust component designed for general electronic equipment applications. With a capacitance of 33µF and a rated voltage of 10V, it provides reliable power storage and filtering. The capacitor's operating temperature range of -55°C to +105°C ensures performance across a broad spectrum of environmental conditions. It is crucial to observe polarity during operation to prevent damage and ensure optimal functionality. Würth Elektronik emphasizes that this product is not intended for use in critical safety applications without proper evaluation and agreement.
WURTH ELEKTRONIK 860160272003 Aluminum Electrolytic Capacitor Specifications:
- A_Dimensions_mm_D_0_5: 5.0
- A_Dimensions_mm_P_0_5: 2.0
- A_Dimensions_mm_L_t: 11.0
- A_Dimensions_mm_t: 1.5
- A_Dimensions_mm_Pin_Ø_0_02: 0.5
- A_Dimensions_mm_a: 2.0
- A_Dimensions_mm_b: 0.8
- Recommended_hole_pattern_mm: Refer to datasheet
- Capacitance: 33 µF
- Rated_voltage_DC: 10 V
- Leakage_current_after_2_min: 3.3 μA
- Dissipation_factor_120_Hz: 19 %
- Ripple_current_100kHz_105C: 72 mA
- Impedance_100kHz_20C: 2.33 Ω
- Operating_Temperature: -55 °C up to +105 ° C
- Load_Life: 4000 h @ +105°C / 10 V (DC)
- Storage_Conditions: 35°C, <45% RH
- Component_Marking_1st_Line: Capacitance value: 33 µF & Rated voltage: 10 V (DC)
- Component_Marking_2nd_Line: WCAP-ATLL & max. operating temperature +105°C
- Component_Marking_3rd_Line: Datecode: YWW
- Component_Marking_4th_Line: VENT marking
- Multiplier_for_Ripple_Current_vs_Frequency_120Hz: 0.47
- Multiplier_for_Ripple_Current_vs_Frequency_400Hz: 0.59
- Multiplier_for_Ripple_Current_vs_Frequency_1000Hz: 0.85
- Multiplier_for_Ripple_Current_vs_Frequency_10000Hz: 0.97
- Multiplier_for_Ripple_Current_vs_Frequency_100000Hz: 1.00
- Preheat_Temperature_Min_Tsmin: 100 °C
- Preheat_Temperature_Typical_Tstypical: 120 °C
- Preheat_Temperature_Max_Tsmax: 130 °C
- Preheat_Time_ts: 70 seconds
- Δ_preheat_to_max_Temperature: 150 °C max.
- Peak_temperature_Tp: 250 °C - 260 °C
- Time_of_actual_peak_temperature_tp: max. 10 seconds
- Ramp_down_rate_Min: ~ 2 K/s
- Ramp_down_rate_Typical: ~ 3.5 K/s
- Ramp_down_rate_Max: ~ 5 K/s
- Time_25C_to_25C: 4 minutes
