WURTH ELEKTRONIK 860240472002 Aluminum Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for electronic applications requiring high reliability and long load life, with a typical capacitance of 33µF rated at 25V DC. It features operating temperatures from -40°C to +105°C and a load life of 5000 hours at +105°C/25V. The capacitor has a vent for pressure relief, polarity marking, and is RoHS & REACH compliant. Suitable for industrial and electronic circuit use, it offers stable electrical properties, low leakage current, and vibration resistance, ensuring dependable performance in demanding environments.
WURTH ELEKTRONIK 860240472002 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 33µF +20%
- Rated Voltage: 25 V DC
- Leakage Current: Max. 8.25 µA after 1 min.
- Dissipation Factor: 14% at 120 Hz
- Ripple Current Multiplier: 0.50 at 120Hz, 0.80 at 1000Hz, 0.85 at 10000Hz, 1.0 at 100000Hz
- Operating Temperature: -40°C to +105°C
- Load Life: 5000 hours at +105°C/25V
- Dimensions: 5.0 x 11.0 mm
- Polarity: Marked by shorter lead and sleeve markings
Buy the WURTH ELECTRONIK 860240472002 – Reliable Electrolytic Capacitor for Industrial Applications
Enhance your electronic circuit designs with this high-quality aluminum electrolytic capacitor. Featuring 33µF capacitance rated at 25V, it operates efficiently between -40°C and +105°C, providing long load life of 5000 hours. RoHS and REACH compliant, it ensures safety and environmental standards. Its robust design includes a vent for pressure relief, polarity markings, and resistance to vibration, making it ideal for industrial, medical, and electronic applications. Buy online today for dependable performance and peace of mind.
Buy WURTH ELECTRONIK 860240472002 aluminum electrolytic capacitor now and experience unmatched reliability and performance in your electronic and industrial projects.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 860240472002?
You can click on the BUY or RFQ button to purchase 860240472002 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 860240472002?
You can download the 860240472002 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 860240472002?
WURTH ELEKTRONIK
