WURTH ELEKTRONIK 865060140002 Aluminum Electrolytic Capacitor
Würth Elektronik offers aluminum electrolytic capacitors designed for electronic circuits requiring reliable power filtering and energy storage. These capacitors operate within -55°C to +105°C and feature a capacitance of 33 uF with a rated voltage of 63V. They are built with high-quality aluminum, have a vent for pressure relief, and are compliant with RoHS and REACH standards. Suitable for various electronic applications, these capacitors ensure stable performance under fluctuating temperatures and electrical loads, making them ideal for power supply, industrial, and general electronic use.
WURTH ELEKTRONIK 865060140002 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 33 uF ±20%
- Rated Voltage: 63 V
- Leakage Current: 3.0 μA max after 2 min
- Dissipation Factor: 22% at 120 Hz
- Ripple Current: 85 mA max at 105°C
- Impedance at 100 kHz: 1.35 Ω max
- Operating Temperature: -55°C to +105°C
- Load Life: 2000 hours at +105°C
- Storage Conditions: 35°C, <45% RH
- Reflow Soldering Profile: Peak at 260°C with controlled ramp rates
- Package Size: 4.0 x 5.5 mm
- Compliance: RoHS & REACH
- Design: Aluminum electrolytic with pressure relief vent
Buy the Wurth Series Electrolytic Capacitor: 33uF 63V - 865060140002
Discover the reliable performance of this aluminum electrolytic capacitor, suitable for power filtering and energy storage in various electronic applications. Operating between -55°C and +105°C, with a capacitance of 33 microfarads at a rated voltage of 63 volts, this component is RoHS and REACH compliant. It features a vent for pressure relief, ensuring safety during operation, and delivers stable electrical characteristics over a load life of 2000 hours. Perfect for industrial, power supply, and general electronic use, order online today for quality assurance and quick delivery.
Order your Würth Series Electrolytic Capacitor with 33uF 63V capacity today and ensure stable power management for your electronic projects with dependable quality.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 865060140002?
You can click on the BUY or RFQ button to purchase 865060140002 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 865060140002?
You can download the 865060140002 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 865060140002?
WURTH ELEKTRONIK
