WAGO 2231302026000 2-pole Female Connector
The WAGO 2231-302/026-000 is a 2-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It offers a push-button design for simple and tool-free wiring, allowing for connection while mated. The connector utilizes push-in CAGE CLAMP® technology for secure termination of both solid and ferruled conductors. It is designed for universal conductor types and includes integrated test ports for convenient testing. This connector is ideal for applications requiring reliable and efficient conductor termination in industrial control panels and machinery.
WAGO 2231302026000 2-pole Female Connector Specifications:
- Material group: I
- Insulation material: Polyamide (PA66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Nominal voltage (III/3): 320 V
- Rated surge voltage (III/3): 4 kV
- Rated voltage (III/2): 320 V
- Rated surge voltage (III/2): 4 kV
- Nominal voltage (II/2): 630 V
- Rated surge voltage (II/2): 4 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group C): 150 V
- Rated current UL (Use Group C): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage UL (1977): 600 V
- Rated current UL (1977): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group C): 150 V
- Rated current CSA (Use Group C): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Push-button
- Solid conductor: 0.2 … 2.5 mm² / 24 … 12 AWG
- Fine-stranded conductor: 0.2 … 2.5 mm² / 24 … 12 AWG
- Fine-stranded conductor; with insulated ferrule: 0.25 … 1.5 mm²
- Fine-stranded conductor; with uninsulated ferrule: 0.25 … 2.5 mm²
- Strip length: 10 … 11 mm / 0.39 … 0.43 inch
- Pole No.: 2
- Total number of connection points: 2
- Total number of potentials: 2
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 11.66 mm / 0.459 inch
- Height: 15 mm / 0.591 inch
- Depth: 25.6 mm / 1.008 inch
- Fire load: 0.071 MJ
- Weight: 3.4 g
- Limit temperature range: -60 … +100 °C
- Packaging type: BOX
- Country of origin: PL
- GTIN: 4045454696474
- Customs tariff number: 85366990990
