WAGO 231102026000 2 Pole Female Plug
The WAGO 231-102/026-000 is a 2-pole female plug connector designed for use in WAGO's multi-connection system. It utilizes a cage clamp connection, ensuring reliable and vibration-resistant terminations. The connector features a 5mm pin spacing and is suitable for a wide range of wire gauges, from 28 AWG to 12 AWG. It is commonly used in industrial control panels, lighting systems, and power distribution applications where secure and efficient connections are required. The closed-end design and coding fingers provide added safety and organization.
WAGO 231102026000 2 Pole Female Plug Specifications:
- product_description: FEMALE PLUG; 2 POLE; PIN SPACING 5 MM / 0.197 IN; WITH CODIG FINGERS; CLOSED END; CAGE CLAMP®CONNECTION
- packing_unit: 200 pieces
- product_group: 3 (Multi Conn. System)
- pin_spacing_mm: 5 mm
- pin_spacing_in: 0.197 in
- pole_count: 2
- cross_section_mm2_min: 0.08 mm²
- cross_section_mm2_max: 2.5 mm²
- cross_section_awg_min: 28 AWG
- cross_section_awg_max: 12 AWG
- connection_method: CAGE CLAMP®CONNECTION
- measured_voltage_en: 250 V
- measured_shock_voltage: 4 kV
- pollution_degree: 3
- current_intensity_en: 16 A
- weight_g: 3.81 g
- color: grey
- no_of_connection_points: 2
- no_of_potentials: 2
- height_mm: 14.3 mm
- height_in: 0.563 in
- width_mm: 11.5 mm
- width_in: 0.453 in
- depth_mm: 26.45 mm
- depth_in: 1.041 in
- strip_length_mm_min: 8 mm
- strip_length_mm_max: 9 mm
- strip_length_in: 0.33 in
- admission_office_abs_approval_no: 04-HG469925-PDA
- admission_office_bv_approval_no: 11915/A0
- admission_office_cca_approval_no: 5764
- admission_office_csa_approval_no: 154112-1466354
- admission_office_demko_approval_no: 88126
- admission_office_gl_approval_no: 17296-00HH
- admission_office_kema_approval_no: 2083746.02
- admission_office_kr_approval_no: HMB05880-EL003
- admission_office_rmr_approval_no: 11130002
- admission_office_ur_approval_no_1: E45171
- admission_office_ur_approval_no_2: E45172
- voltage_abs_bv_cca_demko_gl_kema_rmr_kr_ur_1: 400 V
- voltage_ur_2: 300 V
- current_abs_bv_cca_demko_gl_kema_rmr_kr_ur_1: 16 A
- current_kr: 12/16 A
- cross_section_abs_bv_gl_rmr_ur_1: 5.0 mm²
- cross_section_bv_kema: 2.5 mm²
- cross_section_cca: 0.08-2.5 mm²
- cross_section_csa: 22-12 AWG
- cross_section_ur_2: 12 AWG
