WAGO 231116037000 16-pole Female Plug Connector
The WAGO 231-116/037-000 is a versatile 16-pole female plug connector suitable for a wide range of industrial applications. Its design incorporates a locking lever for secure connections and a 5mm pin spacing for compatibility with various systems. The CAGE CLAMP actuation simplifies wiring, allowing for both vertical and horizontal cable pre-assembly and on-unit wiring. Integrated test ports facilitate easy testing and troubleshooting, while coding fingers ensure correct connection orientation. This connector is ideal for applications requiring reliable and efficient conductor connections in control cabinets and automation systems.
WAGO 231116037000 16-pole Female Plug Connector Specifications:
- Color: gray
- Conductor Size: 0.08 … 2.5 mm² / 28 … 12 AWG
- Pin Spacing: 5 mm
- Number of Poles: 16
- Rated Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 16 A
- UL Voltage (Use Group B): 300 V
- UL Current (Use Group B): 15 A
- UL Voltage (Use Group D): 300 V
- UL Current (Use Group D): 10 A
- Connection Technology: CAGE CLAMP®
- Material: Polyamide 66 (PA 66)
- Flammability Class: V0
- Weight: 29.5 g
- Operating Temperature: -60 … +85 °C
- Product Group: 3 (Multi Conn. System)
