WAGO 231308031000 8-pole Female Connector
The WAGO 231-308/031-000 is a versatile 8-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It offers universal compatibility for all conductor types, simplifying cable pre-assembly and on-unit wiring with its vertical and horizontal CAGE CLAMP actuation. Integrated test ports provide convenient testing capabilities. This connector is ideal for applications requiring reliable and efficient connections in industrial automation, control panels, and power distribution systems. It is RoHS compliant and designed for safe operation within specified voltage and current limits.
WAGO 231308031000 8-pole Female Connector Specifications:
- conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- pin_spacing: 5.08 mm / 0.2 inch
- pole_number: 8
- rated_voltage_iii_3: 320 V
- rated_surge_voltage_iii_3: 4 kV
- rated_voltage_iii_2: 320 V
- rated_surge_voltage_iii_2: 4 kV
- rated_voltage_ii_2: 630 V
- rated_surge_voltage_ii_2: 4 kV
- rated_current: 16 A
- voltage_ul_use_group_b: 300 V
- current_ul_use_group_b: 15 A
- voltage_ul_use_group_d: 300 V
- current_ul_use_group_d: 10 A
- voltage_ul_1977: 600 V
- current_ul_1977: 15 A
- voltage_csa_use_group_b: 300 V
- current_csa_use_group_b: 15 A
- voltage_csa_use_group_d: 300 V
- current_csa_use_group_d: 10 A
- actuation_type: Operating tool
- strip_length: 8 … 9 mm / 0.31 … 0.35 inch
- total_connection_points: 8
- total_potentials: 8
- number_connection_types: 1
- number_levels: 1
- conductor_entry_direction: 0 °
- width: 55.44 mm / 2.183 inch
- height: 14.3 mm / 0.563 inch
- depth: 26.45 mm / 1.041 inch
- mounting_type: Mounting flange, Feed-through mounting, Panel mounting
- contact_type: Female connector/socket
- mismating_protection: No
- color: orange
- insulation_material: Polyamide (PA66)
- flammability_class_ul94: V0
- clamping_spring_material: Chrome nickel spring steel (CrNi)
- contact_material: Copper alloy
- contact_plating: tin-plated
- fire_load: 0.23 MJ
- weight: 15.4 g
- limit_temperature_range: -60 … +85 °C
- product_group: 3 (Multi Conn. System)
- packaging_type: BOX
- country_of_origin: DE
- gtin: 4044918347457
- customs_tariff_number: 85366990990
