WAGO 231312026000 12 Pole Female Plug
The WAGO 231-312/026-000 is a versatile 12-pole female plug within WAGO's Multi Conn. System. It offers a robust and space-saving solution for connecting wires in industrial environments. The innovative cage clamp connection ensures a secure and vibration-resistant connection without the need for special tools. Integrated fixing flanges provide additional stability, while coding fingers prevent incorrect connections. This plug is ideal for applications in control cabinets, machinery, and automation systems where reliable power and signal transmission is critical. It supports a wide range of wire gauges and voltage ratings, making it suitable for diverse electrical projects.
WAGO 231312026000 12 Pole Female Plug Specifications:
- Packing Unit: 25 pieces
- Pin Spacing: 5.08 mm / 0.2 in
- Pole Count: 12
- Cross Section Range (mm²): 0.08-2.5
- Cross Section Range (AWG): 28-12
- Connection Method: CAGE CLAMP®CONNECTION
- Measured Voltage: 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity: 16 A
- Weight: 21.93 g
- Color: orange
- No. of Connection Points: 12
- No. of Potentials: 12
- Height: 14.3 mm
- Height (in): 0.563 in
- Width: 62.46 mm
- Width (in): 2.459 in
- Depth: 26.45 mm
- Depth (in): 1.041 in
- Strip Length: 8-9 mm
- Strip Length (in): 0.33 in
- Admission Office: ABS, BV, CCA, CSA, DEMKO, GL, KEMA, KR, LR, NEMKO, RMR, UR
- Approval No.: 04-HG469925-PDA, 11915/A0, 5764, 154112-1466354, 88126, 17296-00HH, 2083746.02, HMB05880-EL003, 96/20035, P94101840, 11130002, E45171, E45172
- Voltage (V): 250/400/600
- Current (A): 12/16/15
- Cross Section (mm²): 0.8-2.5
