WAGO 231332001000 2-pole THT Header
The WAGO 231-332/001-000 is a robust 2-pole THT (Through-Hole Technology) male header designed for secure and reliable connections in PCB applications. Its 5.08mm pin spacing and 1x1mm solder pin dimensions ensure compatibility with standard layouts. The header's orange polyamide (PA66) housing provides excellent insulation and flame retardancy (UL94 V0). It is suitable for a wide range of industrial applications requiring secure power and signal transmission, and is rated for 320V and 12A. It is RoHS compliant, ensuring environmentally responsible usage.
WAGO 231332001000 2-pole THT Header Specifications:
- Pin Spacing: 5.08 mm
- Number of Poles: 2
- Solder Pin Length: 5 mm
- Solder Pin Dimensions: 1 x 1 mm
- Width: 13.28 mm
- Height: 17 mm
- Height from Surface: 12 mm
- Depth: 8.4 mm
- Drilled Hole Diameter: 1.4 mm
- Nominal Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Current: 12 A
- Material: Polyamide (PA66)
- Flammability Class: UL94 V0
- Contact Material: Electrolytic Copper (E) Cu
- Contact Plating: Tin-plated
- Weight: 0.8 g
- Packaging Type: BOX
- Country of Origin: PL
- GTIN: 4044918865173
- Customs Tariff Number: 85366990990
