WAGO 231533001000 Header Right Angle Connector
The WAGO 231-533/001-000 is a robust 3-pole header connector designed for secure and reliable connections in industrial environments. It offers a right-angle configuration with solder pin connections, facilitating space-saving designs. The connector is constructed with electrolytic copper contacts, tin-plated for enhanced corrosion resistance, and housed in a PA 6.6 insulating material, ensuring temperature stability from -60°C to +100°C. It is compatible with a range of approvals including ABS, BV, CSA, and KEMA, making it suitable for diverse applications requiring stringent safety standards. The connector's robust design and reliable performance make it ideal for applications in automation, control systems, and power distribution.
WAGO 231533001000 Header Right Angle Connector Specifications:
- pole_count: 3
- pin_spacing: 5.08 mm
- mating_direction: parallel to pcb
- closed_end: yes
- packing_unit: 200 (4*50 pieces)
- color: orange
- height: 8.4 mm
- width: 18.44 mm
- depth: 12 mm
- overvoltage_category_en_i_iii: III
- pollution_degree: 2
- measured_voltage_en: 320 V
- measured_shock_voltage: 4 kV
- current_intensity_en: 16 A
- overvoltage_category_en_ii: II
- rated_voltage_en: 250 V
- rated_surge_voltage: 4 kV
- nominal_current: 16 A
- solder_pin_length_mm: 3.8 mm
- solder_pin_width_a_mm: 1 mm
- solder_pin_width_b_mm: 1 mm
- diameter_of_drilled_hole_mm: 1.4 mm
- tolerance_of_drilled_hole_diameter_mm: 0.1 mm
- material_group: I
- insulating_material: PA 6.6
- temperature_stability: -60 °C to +100 °C
- flammability_category_ul94: V0
- contact_material: Electrolytic copper (Ecu)
- contact_plating: tin-plated
- abs_approval_no: 04-HG469925/1-PDA
- bv_approval_no: 11915/A0
- cca_approval_no: 5764
- csa_approval_no: 154112-1466354
- gl_approval_no: 17296-00HH
- kema_approval_no: 2083746.02
- kr_approval_no: HMB05880-EL003
- lr_approval_no: 96/20035
- rmr_approval_no: 11130002
- ur_approval_no: E45172
- voltage_abs: 400 V
- current_abs: 12 A
- cross_section_abs: 0.08-2.5 mm²
- voltage_bv: 400 V
- current_bv: 16 A
- cross_section_bv: 2.5 mm²
- voltage_cca: 250 V
- current_cca: 12 A
- cross_section_cca: 1x1 mm²
- voltage_csa: 300 V
- current_csa: 10 A
- voltage_gl: 400 V
- current_gl: 12 A
- cross_section_gl: 0.08-2.5 mm²
- voltage_kema: 250 V
- current_kema: 12 A
- cross_section_kema: 1x1 mm²
- voltage_kr: 250/400 V
- current_kr: 12/16 A
- cross_section_kr: 2.5 mm²
- voltage_lr: 400 V
- current_lr: 12 A
- cross_section_lr: 0.08-2.5 mm²
- voltage_rmr: 400 V
- current_rmr: 12 A
- cross_section_rmr: 0.08-2.5 mm²
- voltage_ur: 300 V
- current_ur: 10 A
