WAGO 231564108000 4-pole THT Header
The WAGO 231-564/108-000 is a robust 4-pole THT male header designed for reliable PCB connections. Its angled solder pins facilitate easy integration into horizontal or vertical PCB layouts. The threaded flange provides a secure mounting solution, while the 5.08mm pin spacing ensures compatibility with standard spacing requirements. Constructed with polyamide 66 (PA66) for insulation and electrolytic copper with tin plating for conductivity, this header is suitable for a wide range of industrial applications requiring durable and dependable connections. It is rated for nominal voltages up to 250V and currents up to 16A, offering a balance of performance and safety.
WAGO 231564108000 4-pole THT Header Specifications:
- Color: orange
- Pin Spacing: 5.08 mm / 0.2 inch
- Width: 30.32 mm / 1.194 inch
- Height: 12.2 mm / 0.48 inch
- Height from the surface: 8.4 mm / 0.331 inch
- Depth: 12 mm / 0.472 inch
- Solder Pin Length: 3.8 mm
- Solder Pin Dimensions: 1.2 x 1.2 mm
- Drilled Hole Diameter: 1.7 mm (+0.1)
- Nominal Voltage (III/3): 250 V
- Rated Surge Voltage (III/3): 4 kV
- Nominal Voltage (III/2): 320 V
- Rated Surge Voltage (III/2): 4 kV
- Nominal Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 16 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 15 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage UL (1977): 600 V
- Rated Current UL (1977): 15 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 15 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 10 A
- Pole No.: 4
- Total Number of Potentials: 4
- Number of Connection Types: 1
- Number of Levels: 1
- Insulation Material: Polyamide 66 (PA66)
- Flammability Class per UL94: V0
- Contact Material: Electrolytic copper (E) Cu
- Contact Plating: tin-plated
- Fire Load: 0.037 MJ
- Weight: 2.3 g
- Limit Temperature Range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging Type: BOX
- Country of Origin: DE
- GTIN: 4045454843731
- Customs Tariff Number: 85366990990
