WAGO 231604018000 4-pole Male Connector
The WAGO 231-604/018-000 is a versatile 4-pole male connector designed for efficient and reliable connections in diverse industrial settings. It utilizes WAGO's CAGE CLAMP® connection technology for easy cable pre-assembly and on-unit wiring, accommodating both vertical and horizontal actuation. The connector is suitable for wire-to-wire and board-to-wire connections and can be panel or through-panel mounted. It is designed without breaking capacity for compliance with DIN EN 61984 and is ideal for applications requiring robust and secure electrical connections.
WAGO 231604018000 4-pole Male Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 5 mm / 0.197 inch
- Width: 23.2 mm / 0.913 inch
- Height: 18.8 mm / 0.74 inch
- Height from the surface: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Gehäuseblechstärke: 0.6 … 1.2 mm / 0.024 … 0.047 inch
- Material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Weight: 6.5 g
- Limit temperature range: -60 … +100 °C
