WAGO 735500 INTERBUS Fieldbus Connector
The WAGO 750-961 fieldbus connector provides a reliable link between INTERBUS devices and INTERBUS lines. Featuring the innovative CAGE CLAMP connection system, it ensures secure and maintenance-free connections, further enhanced by an actuation slide mechanism. This connector supports a data transmission rate of 2 Mbaud, adhering to INTERBUS specifications, and is suitable for industrial applications requiring robust and efficient fieldbus connectivity. The housing is made of PA66-105-V2 and offers IP20 degree of protection, operating temperatures from 0°C to +60°C, and relative humidity up to 95%.
WAGO 735500 INTERBUS Fieldbus Connector Specifications:
- bus_connector_type: D-Sub female connector
- number_of_poles: 9
- data_transmission_rate: 2 Mbaud
- fixing_screw: UNC- 2 A 4-40
- max_tightening_torque: 0.4 Nm
- housing_material: PA66-105-V2
- housing_color: light gray
- degree_of_protection: IP20
- ambient_operating_temperature: 0°C ... +60°C
- storage_temperature: -25 °C ... +85 °C
- relative_air_humidity: 95 %
- wire_connection: CAGE CLAMP terminal strip with locking slide
- cross_sections: 0.08 mm² ... 0.5 mm² / AWG 28 ... 20
- sep_connection: 0.75 mm² / AWG 18
- stripped_length: see graphic
- min_wire_diameter: 4.5 mm
- max_wire_diameter: 9.5 mm
- approvals_rUL: 508
- approvals_EN: 60079-0, -15 I M2 / II 3 GD Ex nA IIC T4
- approvals_EN_2: 61241-0, -1
