WAGO 231612018000 12-pole Connector
The WAGO 231-612/018-000 is a 12-pole male connector designed for a wide range of industrial applications. Its snap-in mounting feet allow for easy installation, while the CAGE CLAMP® connection technology simplifies wiring and ensures a reliable connection. Compatible with various conductor types and sizes, this connector is ideal for board-to-wire and wire-to-wire connections in control cabinets and automation systems. It meets UL, CSA, and V0 flammability standards for safety and performance.
WAGO 231612018000 12-pole Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 12
- Total number of connection points: 12
- Total number of potentials: 12
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Pin spacing: 5 mm / 0.197 inch
- Width: 63.2 mm / 2.488 inch
- Height: 18.8 mm / 0.74 inch
- Height from the surface: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Gehäuseblechstärke: 0.6 … 1.2 mm / 0.024 … 0.047 inch
- Mounting type: Snap-in mounting foot
- Type of mounting: Panel mounting
- Contact type (pluggable connector): Male connector/plug
- Connector connection type: for conductors
- Mismating protection: No
- Color: gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E Cu)
- Contact plating: tin-plated
- Fire load: 0.329 MJ
- Weight: 18.6 g
- Limit temperature range: -60 … +100 °C
