WAGO 231640 10-pole Male Connector
The WAGO 231-640 is a versatile 10-pole male connector designed for a wide range of industrial applications. Its universal design accommodates all conductor types, simplifying wiring processes. The innovative CAGE CLAMP actuation allows for both vertical and horizontal cable pre-assembly and on-unit wiring, enhancing efficiency and reducing installation time. This connector is ideal for wire-to-wire and board-to-wire connections and is available with snap-in mounting feet or flanges for flexible panel integration. It is designed to meet stringent safety standards and offers reliable performance in demanding environments.
WAGO 231640 10-pole Male Connector Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 10
- Total number of connection points: 10
- Total number of potentials: 10
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 53.4 mm / 2.102 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Contact type (pluggable connector): Male connector/plug
- Material group: I
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Fire load: 0.257 MJ
- Weight: 15.6 g
- Limit temperature range: -60 … +100 °C
