WAGO 231644 1-conductor male connector
The WAGO 231-644 is a 14-pole male connector designed for universal conductor connections. It utilizes the CAGE CLAMP® technology, enabling easy and secure cable pre-assembly and on-unit wiring through both vertical and horizontal actuation. This connector is suitable for a wide range of applications, including wire-to-wire and board-to-wire connections, and is available with various mounting options. It is rated for 320V and 12A, and is UL, CSA, and KEMA certified, making it suitable for diverse industrial environments. The connector's robust design and ease of use contribute to efficient and reliable electrical connections.
WAGO 231644 1-conductor male connector Specifications:
- conductor_size: 0.08 … 2.5 mm² / 28 … 12 AWG
- pin_spacing: 5.08 mm / 0.2 inch
- pole_number: 14
- rated_voltage_iii3: 320 V
- rated_surge_voltage_iii3: 4 kV
- rated_current: 12 A
- material_group: I
- insulation_material: Polyamide (PA66)
- flammability_class_ul94: V0
- color: orange
- width: 74.32 mm / 2.926 inch
- height: 14.3 mm / 0.563 inch
- depth: 27.5 mm / 1.083 inch
- total_connection_points: 14
- total_potentials: 14
- number_of_levels: 1
- conductor_entry_direction: 0 °
- ratings_iec60664_1: 320 V
- ratings_ul_use_group_b: 300 V
- ratings_ul_use_group_d: 300 V
- ratings_ul_1977: 600 V
- ratings_csa_use_group_b: 300 V
- ratings_csa_use_group_d: 300 V
- gtin: 4044918260879
- customs_tariff_number: 85366990990
