WAGO 2716152 2-pole Terminal Strip
The WAGO 2716-152 is a 2-pole terminal strip designed for robust and reliable electrical connections. Featuring lever actuation and a jumper slot, it simplifies wiring and maintenance. The CAGE CLAMP® connection technology ensures secure clamping without the need for tools. Suitable for a wide range of applications including power distribution, control circuits, and automation systems, this terminal strip offers high current carrying capacity and excellent mechanical stability. Its compact design and easy-to-use features make it an ideal choice for industrial environments.
WAGO 2716152 2-pole Terminal Strip Specifications:
- No. of poles: 2
- Pin Spacing: 10 mm
- Total number of connection points: 2
- Total number of potentials: 2
- Color: gray
- Overvoltage category EN 1: III
- Pollution degree (1): 2
- Rated voltage EN (1) [V]: 320
- Rated surge voltage (1) [kV]: 4
- Nominal current [A]: 76
- Overvoltage category EN 2: II
- Degree of pollution (2): 2
- Rated voltage EN (2) [V]: 630
- Rated surge voltage (2) [kV]: 4
- Nominal current (2) [A]: 76
- Overvoltage category EN 3: III
- Degree of pollution (3): 3
- Rated voltage EN (3) [V]: 320
- Rated surge voltage (3) [kV]: 4
- Nominal current (3) [A]: 76
- Number of individual connection objects at the product: 1
- Connection technology (1): CAGE CLAMP®
- Solid sizes 1: 1.5 … 16 mm² / 16 … 6 AWG
- Fine-stranded wires 1: 1.5 … 6 mm² / 16 … 6 AWG
- Fine-stranded wires with insulated ferrule 1: 1.5 … 10 mm² / …
- Fine-stranded wires with uninsulated ferrule 1: 1.5 … 10 mm² / …
- Strip length 1: 12 … 13 mm / 0.47 … 0.51 in
- Conductor entry angle to the PCB 1 [°]: 30
- Solder pin arrangement: in-line solder pin
- Solder pin length [mm]: 4.5
- Solder pin width A [mm]: 0.95
- Solder pin width B [mm]: 1.2
- Tolerance of drilled hole [mm]: 1.6(+ 0.1)
- Material group: I
- Insulating material: Polyamide 66 (PA 66)
- Flammability rating per UL 94: V0
- Limit temperature range: -60 C … 105 C
- Clamping spring material: Chrome-nickel spring steel (CrNi)
- Contact material: Electrolytic copper (Ecu)
- Contact plating: tin-plated
- Fire load [MJ]: 0.354
- Weight [g]: 20.915
- Width: 21.5 mm
- Height: 33.3 mm
- Height from the surface: 28.8 mm
- Length: 35 mm
