WAGO 2734104 4-pole Female Connector
The WAGO 2734-104 is a robust 4-pole female connector within the MCS – MULTI CONNECTION SYSTEM. Its key features include a push-in CAGE CLAMP® connection for easy termination of solid and ferruled conductors, a push-button design that eliminates the need for specialty tools, and a 100% protection against mismating. Integrated test ports allow for parallel conductor testing. This connector is ideal for applications requiring secure and reliable connections in industrial automation, control panels, and power distribution systems. It is compatible with a wide range of conductor sizes and offers excellent insulation and flame retardancy.
WAGO 2734104 4-pole Female Connector Specifications:
- Material: Polyamide (PA66)
- Flammability Class: V0
- Rated Voltage (III/3): 160 V
- Rated Surge Voltage (III/3): 2.5 kV
- Rated Voltage (III/2): 160 V
- Rated Surge Voltage (III/2): 2.5 kV
- Nominal Voltage (II/2): 320 V
- Rated Surge Voltage (II/2): 2.5 kV
- Rated Current: 10 A
- UL Rated Voltage (Use Group B): 300 V
- UL Rated Current (Use Group B): 10 A
- CSA Rated Voltage (Use Group B): 300 V
- CSA Rated Current (Use Group B): 10 A
- Connection Technology: Push-in CAGE CLAMP®
- Solid Conductor Size: 0.2 … 1.5 mm² / 24 … 16 AWG
- Fine-Stranded Conductor Size: 0.2 … 1.5 mm² / 24 … 16 AWG
- Fine-Stranded Conductor with Ferrule Size: 0.25 … 0.75 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule Size: 0.25 … 1.5 mm²
- Strip Length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No.: 4
- Pin Spacing: 3.5 mm / 0.138 inch
- Width: 16.1 mm / 0.634 inch
- Height: 13.5 mm / 0.531 inch
- Depth: 20.4 mm / 0.803 inch
- Mismating Protection: Yes
- Color: light gray
- Fire Load: 0.07 MJ
- Weight: 3.6 g
Buy the 2734-104 WAGO 4-pole Female Connector | myMectronic
Purchase the WAGO 2734-104 connector securely online for reliable performance in your industrial applications.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 2734104?
You can click on the BUY or RFQ button to purchase 2734104 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 2734104?
You can download the 2734104 datasheet or visit the WAGO website for support.
Who is the manufacturer of 2734104?
WAGO
