WAGO 721162001000 2-pole THT Header
The WAGO 721-162/001-000 is a robust 2-pole THT male header suitable for a wide range of industrial applications. Its 5mm pin spacing and 1.2x1.2mm solder pins allow for secure PCB mounting, while the 100% mismating protection ensures reliable connections. Designed for both horizontal and vertical mounting, this header is ideal for applications requiring stable and secure power distribution. It is rated for 250V and 16A, making it suitable for demanding environments. The header is manufactured by WAGO, a trusted name in connection technology.
WAGO 721162001000 2-pole THT Header Specifications:
- Rated voltage (III / 3): 250 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 16 A
- Pin spacing: 5 mm
- Number of poles: 2
- Total number of potentials: 2
- Solder pin length: 5 mm
- Solder pin dimensions: 1.2 x 1.2 mm
- Drilled hole diameter (tolerance): 1.7 mm (- … +0.1)
- Material group: I
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Limit temperature range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918932646
- Customs Tariff No.: 85366990990
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Width: 13.2 mm
- Height: 17 mm
- Height from the surface: 12 mm
- Depth: 11.4 mm
