WAGO 721603019000 3 Pole Connector Block
The WAGO 721-603/019-000 is a 3-pole connector block designed for use in a variety of industrial applications. It features a fixing flange for secure mounting and a 5mm pin spacing for compatibility with standard wiring systems. The CAGE CLAMP® connection ensures a reliable and vibration-resistant connection, while the 100% protection against mismating prevents errors. This connector is suitable for applications requiring a compact and robust solution, such as control cabinets, power distribution systems, and automation equipment. It is also approved by various agencies including ABS, BV, and CSA, ensuring compliance with industry standards.
WAGO 721603019000 3 Pole Connector Block Specifications:
- Product group: 3 (Multi Conn. System)
- Weight: 5.596 g
- Color: light gray
- No. of connection Points: 3
- No. of potentials: 3
- pole count: 3
- Height: 14.3 mm
- Height_in: 0.563 in
- Width: 29.8 mm
- Width_in: 1.173 in
- Depth: 27.5 mm
- Depth_in: 1.083 in
- Pin spacing from: 5 mm
- Pin spacing from_in: 0.197 in
- Pollution degree: 2
- Measured voltage EN: 320 V
- Measured shock voltage: 4 kV
- Current intensity EN: 12 A
- Measured voltage EN_2: 630 V
- Cross section mm2_solid: 0.08 - 2.5 mm²
- Cross section mm2: 0.08 - 2.5 mm²
- Cross section mm2_2: 0.25 - 1.5 mm²
- Cross section mm2_3: 0.25 - 2.5 mm²
- Cross section AWG: 28 - 12 AWG
- Strip length from: 8 mm
- Strip length to: 9 mm
- Material group: I Strain relief plate
- Admission office: ABS
- Approval no.: 04-HG469925/1-PDA
- Voltage [V]: 600
- Current [A]: 20
