WAGO 721164001000 4-pole THT Header
The WAGO 721-164/001-000 is a robust 4-pole THT male header ideal for PCB applications. Its 5mm pin spacing and 1.2x1.2mm solder pins allow for secure and stable connections. The header incorporates a 100% mismating protection feature, enhancing reliability. Designed for horizontal or vertical PCB mounting, this header is rated for 250V and 16A, making it suitable for a wide range of industrial applications. It is manufactured by WAGO, a trusted name in connection technology.
WAGO 721164001000 4-pole THT Header Specifications:
- Rated voltage (III / 3): 250 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 16 A
- Pin spacing: 5 mm
- Number of poles: 4
- Total number of potentials: 4
- Solder pin length: 5 mm
- Solder pin dimensions: 1.2 x 1.2 mm
- Drilled hole diameter (tolerance): 1.7 mm (- … +0.1)
- Material group: I
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Electrolytic copper (E Cu)
- Contact plating: tin-plated
- Fire load: 0.029 MJ
- Weight: 1.7 g
- Limit temperature range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: PL
- GTIN: 4044918932684
- Customs Tariff No.: 85366990990
