WAGO 733364 Right Angle Solder Pin Header
The WAGO 733-364 right-angle solder pin header provides a secure and reliable connection solution for printed circuit boards. Its right-angle design allows for efficient space utilization in compact electronic assemblies. The header features a 4-pole configuration with a 2.5mm pin spacing, ensuring compatibility with standard component layouts. It is 100% protected against mismating, simplifying assembly and reducing errors. The header is suitable for a wide range of industrial applications, including automation, control systems, and power distribution, and is approved by various agencies like ABS, BV, and CSA.
WAGO 733364 Right Angle Solder Pin Header Specifications:
- product_group: Multi Conn. System
- pin_spacing_from_mm: 2.5
- pin_spacing_from_in: 0.098
- pole_count: 4
- measured_voltage_en: 250 V
- measured_shock_voltage: 2.5 kV
- pollution_degree: 2
- current_intensity_en: 4 A
- weight: 0.712 g
- color: light grey
- height_mm: 7.8
- height_in: 0.307
- width_mm: 12.5
- width_in: 0.492
- depth_mm: 8.9
- depth_in: 0.35
- admission_office_abs: 04-HG469925-PDA
- approval_bv: 11915/A0
- approval_cca: NL5640
- approval_csa: 154112-1465035
- voltage_csa: 150 V
- current_csa: 4 A
- cross_section_csa: 28-20
- approval_dnv: E-6997
- approval_gl: 17296-00HH
- approval_kema: 2077592.01
- approval_lr: 96/20035
- approval_rmr: 11130002
- approval_ur_1: E45171
- approval_ur_2: E45172
- voltage_ur_2: 150 V
- current_ur_2: 4 A
- cross_section_ur_2: 28-20
