WAGO 731608 8-pole Connector
The WAGO 731-608 is a robust 8-pole male connector designed for versatile applications in industrial settings. Featuring WAGO’s innovative CAGE CLAMP® connection technology, it enables easy and reliable cable pre-assembly and on-unit wiring, both vertically and horizontally. This connector is suitable for wire-to-wire and board-to-wire connections and is available with various mounting options. It is rated for 500V and 12A, ensuring safe and efficient power transmission. The connector's robust construction and approvals (UL, CSA, IEC) make it ideal for demanding industrial environments.
WAGO 731608 8-pole Connector Specifications:
- Nominal voltage (III/3): 500 V
- Rated surge voltage (III/3): 6 kV
- Rated voltage (III/2): 630 V
- Rated surge voltage (III/2): 6 kV
- Nominal voltage (II/2): 1000 V
- Rated surge voltage (II/2): 6 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage UL (1977): 600 V
- Rated current UL (1977): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor; with insulated ferrule: 0.25 … 1.5 mm²
- Fine-stranded conductor; with uninsulated ferrule: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No.: 8
- Pin spacing: 7.5 mm / 0.295 inch
- Width: 60.7 mm / 2.39 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Contact type (pluggable connector): Male connector/plug
- Mismating protection: No
- Locking of plug-in connection: Without
- Color: gray
- Insulation material: Polyamide (PA66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Fire load: 0.273 MJ
- Weight: 14.1 g
- Total number of connection points: 8
- Total number of potentials: 8
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
