WAGO 734112 12-pole Female Plug
The WAGO 734-112 is a 12-pole female plug connector within the MULTI CONNECTION SYSTEM (MCS). It offers a robust and reliable connection solution for various conductor types, utilizing the innovative CAGE CLAMP technology for easy and secure assembly. The design incorporates features like 100% protection against mismating and coding options for enhanced safety and organization. This connector is ideal for applications in control cabinets, machinery, and automation systems where dependable power and signal transmission are critical. It is designed for use in industrial environments and is suitable for a wide range of applications requiring secure and efficient connections.
WAGO 734112 12-pole Female Plug Specifications:
- Rated voltage (III / 3): 160 V
- Rated impulse voltage (III / 3): 2.5 kV
- Rated voltage (III / 2): 160 V
- Rated impulse voltage (III / 2): 2.5 kV
- Rated voltage (II / 2): 320 V
- Rated impulse voltage (II / 2): 2.5 kV
- Rated current: 10 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Solid conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1.5 mm²
- Strip length: 6 … 7 mm / 0.24 … 0.28 inch
- No. of poles: 12
- Total number of connection points: 12
- Total number of potentials: 12
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 3.5 mm / 0.138 inch
- Width: 44.2 mm / 1.74 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Contact type (pluggable connector): Female connector/socket
- Mismating protection: Yes
- Color: light gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.14 MJ
- Weight: 9.1 g
- Limit temperature range: -60 … +100 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918493680
- Customs Tariff No.: 85366990990
