WAGO 734205 5-pole Female Plug
The WAGO 734-205 is a 5-pole female plug connector designed for versatile applications. Its CAGE CLAMP technology simplifies wiring and ensures secure connections. The design incorporates features like vertical and horizontal actuation, strain relief plates, and coding fingers for enhanced usability and error prevention. It is suitable for a wide range of conductor types and sizes, making it a reliable choice for various industrial and commercial projects. The connector is rated for 160V and 10A, and holds various approvals including UL, CSA, and EN.
WAGO 734205 5-pole Female Plug Specifications:
- Rated Voltage (III / 3): 160 V
- Rated Impulse Voltage (III / 3): 2.5 kV
- Rated Voltage (III / 2): 160 V
- Rated Impulse Voltage (III / 2): 2.5 kV
- Rated Voltage (II / 2): 320 V
- Rated Impulse Voltage (II / 2): 2.5 kV
- Rated Current: 10 A
- UL Rated Voltage (Use Group B): 300 V
- UL Rated Current (Use Group B): 10 A
- UL Rated Voltage (Use Group D): 300 V
- UL Rated Current (Use Group D): 10 A
- CSA Rated Voltage (Use Group B): 300 V
- CSA Rated Current (Use Group B): 10 A
- CSA Rated Voltage (Use Group D): 300 V
- CSA Rated Current (Use Group D): 10 A
- Connection Technology: CAGE CLAMP®
- Actuation Type: Operating tool
- Solid Conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-Stranded Conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-Stranded Conductor with Ferrule: 0.25 … 1.5 mm²
- Strip Length: 6 … 7 mm / 0.24 … 0.28 inch
- Number of Poles: 5
- Pin Spacing: 3.81 mm / 0.15 inch
- Width: 21.25 mm / 0.837 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Material Group: I
- Insulating Material: Polyamide 66 (PA 66)
- Flammability Class: V0
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Fire Load: 0.076 MJ
- Weight: 4.3 g
- Limit Temperature Range: -60 … +100 °C
- Packaging Type: BOX
- Country of Origin: DE
- GTIN: 4044918494151
- Customs Tariff No.: 85366990990
