WAGO 734210 10-Conductor Female Plug
The WAGO 734-210 is a versatile 10-conductor female plug designed for use within the MULTI CONNECTION SYSTEM (MCS). It offers universal compatibility with all conductor types and incorporates WAGO’s innovative CAGE CLAMP® actuation for simplified cable pre-assembly and on-unit wiring. The plug’s design includes 100% protection against mismating and allows for coding via coding fingers. It is suitable for a wide range of industrial applications requiring reliable and efficient electrical connections, and is designed to be used with appropriate ferrule sizes for optimal performance. Note that terminating 1.5 mm² conductors may require careful consideration due to insulation diameter limitations.
WAGO 734210 10-Conductor Female Plug Specifications:
- Rated voltage (III / 3): 160 V
- Rated impulse voltage (III / 3): 2.5 kV
- Rated voltage (III / 2): 160 V
- Rated impulse voltage (III / 2): 2.5 kV
- Rated voltage (II / 2): 320 V
- Rated impulse voltage (II / 2): 2.5 kV
- Rated current: 10 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Solid conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1.5 mm²
- Strip length: 6 … 7 mm / 0.24 … 0.28 inch
- No. of poles: 10
- Total number of connection points: 10
- Total number of potentials: 10
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 3.81 mm / 0.15 inch
- Width: 40.3 mm / 1.587 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Contact type: Female connector/socket
- Mismating protection: Yes
- Color: orange
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.146 MJ
- Weight: 8.3 g
- Limit temperature range: -60 … +100 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918494205
- Customs Tariff No.: 85366990990
