WAGO 231738001000 8-pole THT Header
The WAGO 231-738/001-000 is a robust 8-pole THT (Through-Hole Technology) male header designed for secure and reliable PCB connections. It offers a 1.0 x 1.0 mm solder pin, ensuring compatibility with standard PCB layouts. The straight pin configuration allows for easy integration into various circuit designs. With a pin spacing of 7.62 mm, this header provides ample space for connections and reduces the risk of shorts. Its orange color facilitates easy identification and organization within complex assemblies. This component is ideal for applications requiring durable and high-performance connections in industrial automation, control systems, and power distribution.
WAGO 231738001000 8-pole THT Header Specifications:
- Pin Cross-section: 1 x 1 mm
- Pin Spacing: 7.62 mm
- Number of Poles: 8
- Color: orange
- Solder Pin Length: 5 mm
- Drilled Hole Diameter: 1.4 mm (+0.1)
- Nominal Voltage (III/3): 500 V
- Rated Surge Voltage (III/3): 6 kV
- Rated Voltage (III/2): 630 V
- Rated Current: 12 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 10 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Material: Polyamide (PA66)
- Flammability Class: V0
- Contact Material: Electrolytic Copper (E Cu)
- Contact Plating: tin-plated
- Limit Temperature Range: -60 … +100 °C
- Packaging Type: BOX
- Country of Origin: PL
- GTIN: 4044918867894
- Customs Tariff Number: 85366990990
Buy the 231-738/001-000 WAGO 8-pole THT Header | myMectronic
Purchase the WAGO 231-738/001-000 securely and reliably online for your industrial automation needs.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 231738001000?
You can click on the BUY or RFQ button to purchase 231738001000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 231738001000?
You can download the 231738001000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 231738001000?
WAGO
