WAGO 769108 8-pole Female Plug Connector
The WAGO 769-108 is a robust 8-pole female plug connector engineered for use in various industrial applications. Its CAGE CLAMP® connection technology provides a secure and vibration-resistant connection for conductors ranging from 0.08 to 4 mm². The connector is rated for a voltage of 500V and a current of 32A, making it suitable for demanding electrical systems. It is compliant with EN 61984 and IEC 60664-1 standards, ensuring safety and reliability. The connector's modular design allows for easy integration into WAGO terminal strip systems, simplifying installation and maintenance. It is commonly used in control cabinets, automation systems, and power distribution panels.
WAGO 769108 8-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 500 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 32 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Nominal cross section: 4 mm²
- Solid conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 8
- Total number of connection points: 8
- Total number of potentials: 8
- Type of wiring: Front-entry wiring
- Width: 40 mm / 1.575 inch
- Height: 45.2 mm / 1.78 inch
- Depth: 18.3 mm / 0.72 inch
- Module width: 5 mm / 0.197 inch
- Marking level: Side marking
- Contact type (pluggable connector): Female connector/socket
- Connector connection type: for conductors
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.426 MJ
- Weight: 27.321 g
- Country of origin: DE
- GTIN: 4044918471619
- Customs Tariff No.: 85366990990
