WAGO 769608005000 8-pole Male Connector
The WAGO 769-608/005-000 is an 8-pole male connector designed for robust and secure connections in industrial automation, control, and power distribution systems. It utilizes WAGO's CAGE CLAMP[®] connection technology for reliable termination and easy maintenance. The snap-in flange allows for simple mounting, while the 4mm² cross-section and 5mm pin spacing provide flexibility in wiring configurations. This connector is rated for 500V and 32A, making it suitable for demanding applications. It is RoHS compliant and designed to withstand harsh environmental conditions.
WAGO 769608005000 8-pole Male Connector Specifications:
- Rated voltage (III / 3): 500 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 32 A
- Connection technology: CAGE CLAMP[®]
- Nominal cross section: 4 mm²
- Solid conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 8
- Total number of connection points: 8
- Total number of potentials: 8
- Type of wiring: Front-entry wiring
- Pin spacing: 5 mm / 0.197 inch
- Width: 61.3 mm / 2.413 inch
- Height: 24.4 mm / 0.961 inch
- Depth: 40.8 mm / 1.606 inch
- Mounting type: Snap-in
- Contact type (pluggable connector): Male connector/plug
- Connector connection type: for conductors
- Color: gray
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.52 MJ
- Weight: 25.4 g
- Product Group: 18 (X-COM-System)
- Packaging type: BOX
- Country of origin: PL
- GTIN: 4044918840958
- Customs Tariff No.: 85366990990
