WAGO 859303 Relay Module
The WAGO 859-303 relay module provides a reliable solution for switching applications in industrial environments. With a nominal input voltage of 12VDC and a single changeover contact, it offers flexibility in circuit design. The integrated red status indicator allows for quick visual confirmation of the relay's operational state. Designed for DIN-35 rail mounting, this module simplifies installation and integration into existing control systems. It's suitable for applications requiring reliable switching and status indication, ensuring efficient and safe operation.
WAGO 859303 Relay Module Specifications:
- Nominal input voltage UN: DC 12 V
- Input voltage range: -15 … +20 %
- Nominal input current at UN: 17 mA
- Number of changeover/switchover contacts: 1
- Contact material (relay): AgSnO2
- Limiting continuous current: 5 A
- Max. make current (resistive): (AC) 20 A / 0.02 s
- Max. switching voltage: AC 250 V
- Max. switching power (resistive): AC 1250 VA
- Recommended minimum load: 10 V / 10 mA; 24 V / 1 mA
- Pull-in time (typ.): 15 ms
- Drop-out time (typ.): 25 ms
- Bounce time (typ.): 3.5 ms
- Electrical life (N.O.; resistive load; 23 °C): 50 x 10^3 switching operations
- Mechanical life: 5 x 10^6 switching operations
- Max. switching load with load/without load: 6 min / 180 min
- Status indication LED: red
- Rated impulse voltage: 4 kV
- Pollution degree: 2
- Dielectric strength, control/load circuit (AC, 1 min): 4 kVrms
- Dielectric strength open contact (AC, 1 min): 1 kVrms
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
- Strip length: 5 … 6 mm / 0.2 … 0.24 inch
- Width: 6 mm / 0.236 inch
- Height from upper-edge of DIN-35 rail: 56 mm / 2.205 inch
- Depth: 91 mm / 3.583 inch
- Color: gray
- Weight: 22.1 g
- Surrounding air (operating) temperature at UN: -40 … 50 °C
- Surrounding air (storage) temperature: -40 … 70 °C
- Processing temperature: -25 … +50 °C
- Standards and specifications: EN 61010-2-201; EN 61810-1; EN 61373; GL; UL 508
