WEIDMULLER 1234600000 PCB terminal connector
This PCB terminal features a leaf spring connection at a 5.08 mm pitch, supporting conductor cross-sections up to 2.5 mm² or 14-26 AWG. Designed for reliable 600 V IEC and 300 V UL rated performances, it provides secure clamp connection with a maximum clamping range of 2.5 mm². Suitable for PCB mounting with 3.5 mm solder pin length, the terminal is also rated for 24 A IEC and 15 A UL, ensuring efficient electrical connection in various control and automation applications. Its orange insulation and tinned copper contact surface enhance durability and safety.
WEIDMULLER 1234600000 PCB terminal connector Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of Poles: 8
- Solder pin length: 3.5 mm
- Rated voltage: IEC 600 V, UL 300 V
- Rated current: IEC 24 A, UL 15 A
- Wire cross-section: 0.13 - 2.5 mm² (AWG 26 - 14)
- Clamping range: 0.13 - 2.5 mm² (AWG 26 - 14)
- Conductor outlet direction: 90°
- Material: Insulating Wemid (PA), Copper alloy contact surface tinned
- Insulation color: Orange
- Contact surface: Tinned with 1-3 μm Ni, 4-6 μm Sn
- Tinning layer: 1.5 - 3.5 μm Ni / 4 - 6 μm Sn
- Operating temperature: -60°C to +120°C
- Maximum storage humidity: 80%
Buy the Weidmueller Series PCB Terminal: 8 Poles 5.08mm Pitch PM 5.08/08/90 3.5SN OR BX
Secure your electrical connections with the Weidmueller PCB terminal featuring a leaf spring mechanism, 8 poles, and 5.08 mm pitch. Rated for 600 V IEC and 300 V UL, it supports conductor cross-sections from 0.13 to 2.5 mm² (AWG 26-14). Its robust orange insulation ensures safety and durability, ideal for control panels and automation modules. Easy to mount with 3.5 mm solder pins, this terminal delivers reliable, efficient electrical connectivity with rated 24 A IEC and 15 A UL currents. Perfect for industrial wiring and PCB applications.
Buy Weidmueller PM 5.08/08/90 3.5SN OR BX now and experience unmatched reliability and performance in PCB wiring and automation systems.
