WEIDMULLER 1278300000 Push-in connector
The Weidmüller B2CF 3.50/18/180LR SN BK BX is a two-row female plug with PUSH IN spring connection, designed for easy wire insertion and tool-free locking with optional release latch or lever. Its 3.50 mm pitch and 180° conductor outlet facilitate high-density installation. Suitable for PLC and industrial automation applications, it supports 1.5 mm² conductor cross-sections, offers UL, IEC, and CSA certifications, and features a DIN VDE touch-safe design with IP20 protection. Constructed from durable PA 66 GF 30 with tin-plated copper contacts, it ensures reliable, long-lasting performance in harsh environments.
WEIDMULLER 1278300000 Push-in connector Specifications:
- Type: Push-in connector, female plug
- Number of poles: 18
- Pitch: 3.5 mm (0.138 inch)
- Conductor cross-section: 1.5 mm² (AWG 26-16)
- Rated voltage IEC: 320 V, UL: 300 V, CSA: 300 V
- Rated current: 13.4 A (IEC), 10-12 A (UL/CSA)
- Temperature range: -60°C to 120°C
- Insulation material: PA 66 GF 30, black, RAL 9011
- Contact material: Copper alloy, tin-plated
- Protection class: IP20, touch-safe
- Max conductor diameter: 2.6 mm
- Stripping length: 10 mm
- Number of wiring cycles: 25
- Clamping range: 0.14 mm² to 1.5 mm²
- UL, IEC, CSA certifications
- Dimensions: 28 mm width, 14 mm height, 14 mm depth
- Operating temperature: -60°C to 120°C
- Packaging: Box
Buy the Buy Weidmüller B2CF 3.50/18/180LR SN BK BX Part Number 1278300000 Online
Order the Weidmüller B2CF 3.50/18/180LR SN BK BX online today for reliable high-density wiring solutions. Its push-in connection design allows quick, tool-free wire insertion, reducing installation time. With a compact 3.5 mm pitch and 18 poles, it offers excellent performance in industrial automation systems. Certified for UL, IEC, and CSA standards, this durable connector features a touch-safe IP20 design, tin-plated copper contacts, and a temperature range from -60°C to 120°C. Perfect for control panels and machinery wiring, it ensures safety, efficiency, and longevity in demanding environments.
Get Weidmüller B2CF 3.50/18/180LR SN BK BX today—built for precision and long-lasting durability in industrial automation.
