WEIDMULLER 2013870000 PCB Terminal Connector
The PCB terminal connector features a 10.16 mm pitch, with a clamping yoke connection capable of handling wire cross-sections up to 16 mm² and currents up to 76 A. Designed for PCB mounting via THT soldering, it offers 4 poles with offset solder pins, test points, and a conductor outlet at 90°. Constructed with tinned copper contact surfaces and black Wemid (PA) insulation, it’s rated for 1000 V and UL/IEC standards, making it suitable for power electronics, industrial automation, and control systems. The compact dimensions include width 41.44 mm, height 36.5 mm, and depth 25.1 mm.
WEIDMULLER 2013870000 PCB Terminal Connector Specifications:
- Pitch: 10.16 mm (0.4 inch)
- Number of poles: 4
- Conductor outlet: 90°
- Solder pin length: 5 mm
- Max. clamping range: 16 mm²
- Rated voltage: 1000 V / 600 V (UL)
- Rated current: 76 A / 51 A (UL/IEC)
- Wire cross-section: AWG 22 to AWG 6
- Material: Copper contact, tinned, insulating with Wemid (PA), black
- Dimensions: Width 41.44 mm, height 36.5 mm, depth 25.1 mm
- Operating temperature: -50°C to 120°C
- Flammability: UL 94V-0
- Insulating material group: I
- Certification: UL, IEC, CSA, RoHS compliant
- Contact surface: Tinned copper
Buy the Buy Weidmueller PCB Terminal Part Number 2013870000 Online
Purchase the Weidmueller PCB terminal connector with 10.16 mm pitch, 4 poles, and rated for 1000 V and 76 A. Its robust clamping yoke connection supports up to 16 mm² wire cross-section, ideal for power electronics, automation, and control circuits. Easy PCB mounting with THT soldering, compact dimensions, and high-quality materials ensure durability and safety. Order online today to improve your installation efficiency and ensure reliable electrical connections in your industrial projects.
Buy Weidmueller PCB terminal connector with 10.16 mm pitch, 4 poles, and high current capacity now and experience unmatched reliability and power efficiency.
Frequently Asked Questions
Where can I buy WEIDMULLER 2013870000?
You can click on the BUY or RFQ button to purchase 2013870000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2013870000?
You can download the 2013870000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2013870000?
WEIDMULLER
