WEIDMULLER 2014760000 Power Terminal Block
The PCB terminal provides reliable connections up to 1000 V and 76 A, with a 16 mm conductor cross-section and proven clamping yoke connection. Designed for robust industrial applications, it features an 8-pole configuration, 12.7 mm pitch, and a 90° conductor outlet. Suitable for PCB mounting via THT soldering, it offers assured electrical and mechanical performance with verified safety standards. Its dimensions ensure easy integration into complex systems, making it an essential component for efficient power distribution and control in industrial environments.
WEIDMULLER 2014760000 Power Terminal Block Specifications:
- Number of Poles: 8
- Pitch in mm: 12.7 mm
- Pitch in inches: 0.5 inch
- Solder Pin Length: 5 mm
- Maximum Clamping Range: 16 mm
- Rated Voltage IEC: 1000 V
- Rated Current IEC: 76 A
- Rated Voltage UL: 600 V
- Rated Current UL: 65 A
- Wire Cross-Section AWG: 22 - 6
- Solder Pin Dimensions: 12 x 1.2 mm
- Solder Eyelet Hole Diameter: 1.6 mm
- Insulating Material: Wemid (PA), Black, UL 94 V0
- Contact Material: Tinned Copper
- Temperature Rating: -50°C to 120°C
- Dimensions: Width 99.86 mm, Height 36.5 mm, Depth 25.1 mm
- Weight: 81.569 g
- Connection Method: Clamping yoke, THT soldering
- Protection: IP20 when plugged, IP10 unplugged
- Tightening Torque: 1.2–1.5 Nm
- Operating and Storage Temperature Min/Max: -50°C to 120°C
Buy the Weidmueller LUP 12.70/08/90 5.0SN – Reliable PCB Power Terminal for Industrial Applications
Purchase Weidmueller Power Terminal Block today for robust power distribution in industrial automation systems. Designed for high voltage and current ratings, it ensures reliable connections up to 1000 V and 76 A with easy PCB mounting via THT. Its proven clamping yoke connection guarantees secure conductor fixation, and its dimensions ensure compatibility with complex power control setups. Equip your systems with this industrial-grade terminal block for safe, efficient, and long-lasting electrical connections in demanding environments.
Get Weidmueller LUP 12.70/08/90 5.0SN today—designed for high power, durability, and seamless PCB mounting in industrial environments.
Frequently Asked Questions
Where can I buy WEIDMULLER 2014760000?
You can click on the BUY or RFQ button to purchase 2014760000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2014760000?
You can download the 2014760000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2014760000?
WEIDMULLER
